Spring Boot + Spring data JPA

spring boot spring data jpa

In this tutorial, we will show you how to use Spring Boot + Spring data JPA to save data into an H2 in-memory database and how to also query the data.

Technologies used :

  • Spring Boot 2.1.2.RELEASE
  • Spring 5.1.4.RELEASE
  • Hibernate 5.3.7
  • HikariCP 3.2.0
  • H2 in-memory database 1.4.197
  • Maven 3
  • Java 8
Note
By default, Spring Boot 2 uses HikariCP as the database connection pool. Read this Spring Boot algorithm to choose a pool implementation.

1. Project Directory

project directory

2. Maven

Puts spring-boot-starter-data-jpa, it will get Spring data, Hibernate, HikariCP and all databases related dependencies.

pom.xml

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0
		 http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>

    <artifactId>spring-data-jpa</artifactId>
    <packaging>jar</packaging>
    <name>Spring Boot Spring Data JPA</name>
    <version>1.0</version>

    <parent>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-parent</artifactId>
        <version>2.1.2.RELEASE</version>
    </parent>

    <properties>
        <java.version>1.8</java.version>
        <downloadSources>true</downloadSources>
        <downloadJavadocs>true</downloadJavadocs>
    </properties>

    <dependencies>

        <!-- jpa, crud repository -->
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-data-jpa</artifactId>
        </dependency>

        <!-- in-memory database  -->
        <dependency>
            <groupId>com.h2database</groupId>
            <artifactId>h2</artifactId>
        </dependency>

        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-test</artifactId>
            <scope>test</scope>
        </dependency>

    </dependencies>

    <build>
        <plugins>

            <plugin>
                <groupId>org.springframework.boot</groupId>
                <artifactId>spring-boot-maven-plugin</artifactId>
            </plugin>

            <plugin>
                <groupId>org.apache.maven.plugins</groupId>
                <artifactId>maven-surefire-plugin</artifactId>
                <version>2.22.0</version>
            </plugin>

        </plugins>

    </build>
</project>

Display the project dependencies.


$ mvn dependency:tree

[INFO] org.springframework.boot:spring-boot-data-jpa:jar:1.0
[INFO] +- org.springframework.boot:spring-boot-starter-data-jpa:jar:2.1.2.RELEASE:compile
[INFO] |  +- org.springframework.boot:spring-boot-starter-aop:jar:2.1.2.RELEASE:compile
[INFO] |  |  +- org.springframework:spring-aop:jar:5.1.4.RELEASE:compile
[INFO] |  |  \- org.aspectj:aspectjweaver:jar:1.9.2:compile
[INFO] |  +- org.springframework.boot:spring-boot-starter-jdbc:jar:2.1.2.RELEASE:compile
[INFO] |  |  +- com.zaxxer:HikariCP:jar:3.2.0:compile
[INFO] |  |  \- org.springframework:spring-jdbc:jar:5.1.4.RELEASE:compile
[INFO] |  +- javax.transaction:javax.transaction-api:jar:1.3:compile
[INFO] |  +- javax.xml.bind:jaxb-api:jar:2.3.1:compile
[INFO] |  |  \- javax.activation:javax.activation-api:jar:1.2.0:compile
[INFO] |  +- org.hibernate:hibernate-core:jar:5.3.7.Final:compile
[INFO] |  |  +- org.jboss.logging:jboss-logging:jar:3.3.2.Final:compile
[INFO] |  |  +- javax.persistence:javax.persistence-api:jar:2.2:compile
[INFO] |  |  +- org.javassist:javassist:jar:3.23.1-GA:compile
[INFO] |  |  +- net.bytebuddy:byte-buddy:jar:1.9.7:compile
[INFO] |  |  +- antlr:antlr:jar:2.7.7:compile
[INFO] |  |  +- org.jboss:jandex:jar:2.0.5.Final:compile
[INFO] |  |  +- com.fasterxml:classmate:jar:1.4.0:compile
[INFO] |  |  +- org.dom4j:dom4j:jar:2.1.1:compile
[INFO] |  |  \- org.hibernate.common:hibernate-commons-annotations:jar:5.0.4.Final:compile
[INFO] |  +- org.springframework.data:spring-data-jpa:jar:2.1.4.RELEASE:compile
[INFO] |  |  +- org.springframework.data:spring-data-commons:jar:2.1.4.RELEASE:compile
[INFO] |  |  +- org.springframework:spring-orm:jar:5.1.4.RELEASE:compile
[INFO] |  |  +- org.springframework:spring-context:jar:5.1.4.RELEASE:compile
[INFO] |  |  |  \- org.springframework:spring-expression:jar:5.1.4.RELEASE:compile
[INFO] |  |  +- org.springframework:spring-tx:jar:5.1.4.RELEASE:compile
[INFO] |  |  +- org.springframework:spring-beans:jar:5.1.4.RELEASE:compile
[INFO] |  |  \- org.slf4j:slf4j-api:jar:1.7.25:compile
[INFO] |  \- org.springframework:spring-aspects:jar:5.1.4.RELEASE:compile
[INFO] +- com.h2database:h2:jar:1.4.197:compile
[INFO] \- org.springframework.boot:spring-boot-starter-test:jar:2.1.2.RELEASE:test
[INFO]    +- org.springframework.boot:spring-boot-starter:jar:2.1.2.RELEASE:compile
[INFO]    |  +- org.springframework.boot:spring-boot:jar:2.1.2.RELEASE:compile
[INFO]    |  +- org.springframework.boot:spring-boot-autoconfigure:jar:2.1.2.RELEASE:compile
[INFO]    |  +- org.springframework.boot:spring-boot-starter-logging:jar:2.1.2.RELEASE:compile
[INFO]    |  |  +- ch.qos.logback:logback-classic:jar:1.2.3:compile
[INFO]    |  |  |  \- ch.qos.logback:logback-core:jar:1.2.3:compile
[INFO]    |  |  +- org.apache.logging.log4j:log4j-to-slf4j:jar:2.11.1:compile
[INFO]    |  |  |  \- org.apache.logging.log4j:log4j-api:jar:2.11.1:compile
[INFO]    |  |  \- org.slf4j:jul-to-slf4j:jar:1.7.25:compile
[INFO]    |  +- javax.annotation:javax.annotation-api:jar:1.3.2:compile
[INFO]    |  \- org.yaml:snakeyaml:jar:1.23:runtime
[INFO]    +- org.springframework.boot:spring-boot-test:jar:2.1.2.RELEASE:test
[INFO]    +- org.springframework.boot:spring-boot-test-autoconfigure:jar:2.1.2.RELEASE:test
[INFO]    +- com.jayway.jsonpath:json-path:jar:2.4.0:test
[INFO]    |  \- net.minidev:json-smart:jar:2.3:test
[INFO]    |     \- net.minidev:accessors-smart:jar:1.2:test
[INFO]    |        \- org.ow2.asm:asm:jar:5.0.4:test
[INFO]    +- junit:junit:jar:4.12:test
[INFO]    +- org.assertj:assertj-core:jar:3.11.1:test
[INFO]    +- org.mockito:mockito-core:jar:2.23.4:test
[INFO]    |  +- net.bytebuddy:byte-buddy-agent:jar:1.9.7:test
[INFO]    |  \- org.objenesis:objenesis:jar:2.6:test
[INFO]    +- org.hamcrest:hamcrest-core:jar:1.3:test
[INFO]    +- org.hamcrest:hamcrest-library:jar:1.3:test
[INFO]    +- org.skyscreamer:jsonassert:jar:1.5.0:test
[INFO]    |  \- com.vaadin.external.google:android-json:jar:0.0.20131108.vaadin1:test
[INFO]    +- org.springframework:spring-core:jar:5.1.4.RELEASE:compile
[INFO]    |  \- org.springframework:spring-jcl:jar:5.1.4.RELEASE:compile
[INFO]    +- org.springframework:spring-test:jar:5.1.4.RELEASE:test
[INFO]    \- org.xmlunit:xmlunit-core:jar:2.6.2:test

3. Spring Data JPA

Book.java

package com.mkyong;

import javax.persistence.Entity;
import javax.persistence.GeneratedValue;
import javax.persistence.GenerationType;
import javax.persistence.Id;

@Entity
public class Book {

    @Id
    @GeneratedValue(strategy = GenerationType.AUTO)
    private Long id;
    private String name;

    public Book() {
    }

    public Book(String name) {
        this.name = name;
    }

    //getters, setters, toString...
}
BookRepository.java

package com.mkyong;

import org.springframework.data.repository.CrudRepository;

import java.util.List;

public interface BookRepository extends CrudRepository<Book, Long> {

    List<Book> findByName(String name);

}

4. @SpringBootApplication

4.1 Start Spring Boot, inserts 3 books into the H2 database, and test the find() method.

StartApplication.java

package com.mkyong;

import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.boot.CommandLineRunner;
import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;

@SpringBootApplication
public class StartApplication implements CommandLineRunner {

    private static final Logger log = LoggerFactory.getLogger(StartApplication.class);

    @Autowired
    private BookRepository repository;

    public static void main(String[] args) {
        SpringApplication.run(StartApplication.class, args);
    }

    @Override
    public void run(String... args) {

        log.info("StartApplication...");

        repository.save(new Book("Java"));
        repository.save(new Book("Node"));
        repository.save(new Book("Python"));

        System.out.println("\nfindAll()");
        repository.findAll().forEach(x -> System.out.println(x));

        System.out.println("\nfindById(1L)");
        repository.findById(1l).ifPresent(x -> System.out.println(x));

        System.out.println("\nfindByName('Node')");
        repository.findByName("Node").forEach(x -> System.out.println(x));

    }

}

5. HikariCP Connection Pool

By default, Spring Boot 2 uses HikariCP as the default connection pool.

5.1 Enable the logging level of com.zaxxer to debug, it will print out the default HikariCP configuration.

application.properties

logging.level.org.springframework=INFO
logging.level.com.mkyong=INFO
logging.level.com.zaxxer=DEBUG
logging.level.root=ERROR

5.2 Run the Spring Boot, review the logging :


DEBUG com.zaxxer.hikari.HikariConfig - Driver class org.h2.Driver found in Thread context class loader jdk.internal.loader.ClassLoaders$AppClassLoader@28c97a5
DEBUG com.zaxxer.hikari.HikariConfig - HikariPool-1 - configuration:
DEBUG com.zaxxer.hikari.HikariConfig - allowPoolSuspension.............false
DEBUG com.zaxxer.hikari.HikariConfig - autoCommit......................true
DEBUG com.zaxxer.hikari.HikariConfig - catalog.........................none
DEBUG com.zaxxer.hikari.HikariConfig - connectionInitSql...............none
DEBUG com.zaxxer.hikari.HikariConfig - connectionTestQuery.............none
DEBUG com.zaxxer.hikari.HikariConfig - connectionTimeout...............30000
DEBUG com.zaxxer.hikari.HikariConfig - dataSource......................none
DEBUG com.zaxxer.hikari.HikariConfig - dataSourceClassName.............none
DEBUG com.zaxxer.hikari.HikariConfig - dataSourceJNDI..................none
DEBUG com.zaxxer.hikari.HikariConfig - dataSourceProperties............{password=<masked>}
DEBUG com.zaxxer.hikari.HikariConfig - driverClassName................."org.h2.Driver"
DEBUG com.zaxxer.hikari.HikariConfig - healthCheckProperties...........{}
DEBUG com.zaxxer.hikari.HikariConfig - healthCheckRegistry.............none
DEBUG com.zaxxer.hikari.HikariConfig - idleTimeout.....................600000
DEBUG com.zaxxer.hikari.HikariConfig - initializationFailTimeout.......1
DEBUG com.zaxxer.hikari.HikariConfig - isolateInternalQueries..........false
DEBUG com.zaxxer.hikari.HikariConfig - jdbcUrl.........................jdbc:h2:mem:testdb;DB_CLOSE_DELAY=-1;DB_CLOSE_ON_EXIT=FALSE
DEBUG com.zaxxer.hikari.HikariConfig - leakDetectionThreshold..........0
DEBUG com.zaxxer.hikari.HikariConfig - maxLifetime.....................1800000
DEBUG com.zaxxer.hikari.HikariConfig - maximumPoolSize.................10
DEBUG com.zaxxer.hikari.HikariConfig - metricRegistry..................none
DEBUG com.zaxxer.hikari.HikariConfig - metricsTrackerFactory...........none
DEBUG com.zaxxer.hikari.HikariConfig - minimumIdle.....................10
DEBUG com.zaxxer.hikari.HikariConfig - password........................<masked>
DEBUG com.zaxxer.hikari.HikariConfig - poolName........................"HikariPool-1"
DEBUG com.zaxxer.hikari.HikariConfig - readOnly........................false
DEBUG com.zaxxer.hikari.HikariConfig - registerMbeans..................false
DEBUG com.zaxxer.hikari.HikariConfig - scheduledExecutor...............none
DEBUG com.zaxxer.hikari.HikariConfig - schema..........................none
DEBUG com.zaxxer.hikari.HikariConfig - threadFactory...................internal
DEBUG com.zaxxer.hikari.HikariConfig - transactionIsolation............default
DEBUG com.zaxxer.hikari.HikariConfig - username........................"sa"
DEBUG com.zaxxer.hikari.HikariConfig - validationTimeout...............5000
INFO  com.zaxxer.hikari.HikariDataSource - HikariPool-1 - Starting...
DEBUG com.zaxxer.hikari.pool.HikariPool - HikariPool-1 - Added connection conn0: url=jdbc:h2:mem:testdb user=SA
INFO  com.zaxxer.hikari.HikariDataSource - HikariPool-1 - Start completed.
DEBUG com.zaxxer.hikari.pool.HikariPool - HikariPool-1 - Pool stats (total=1, active=0, idle=1, waiting=0)
DEBUG com.zaxxer.hikari.pool.HikariPool - HikariPool-1 - Added connection conn1: url=jdbc:h2:mem:testdb user=SA
DEBUG com.zaxxer.hikari.pool.HikariPool - HikariPool-1 - Added connection conn2: url=jdbc:h2:mem:testdb user=SA
DEBUG com.zaxxer.hikari.pool.HikariPool - HikariPool-1 - Added connection conn3: url=jdbc:h2:mem:testdb user=SA
DEBUG com.zaxxer.hikari.pool.HikariPool - HikariPool-1 - Added connection conn4: url=jdbc:h2:mem:testdb user=SA
DEBUG com.zaxxer.hikari.pool.HikariPool - HikariPool-1 - Added connection conn5: url=jdbc:h2:mem:testdb user=SA
DEBUG com.zaxxer.hikari.pool.HikariPool - HikariPool-1 - Added connection conn6: url=jdbc:h2:mem:testdb user=SA
DEBUG com.zaxxer.hikari.pool.HikariPool - HikariPool-1 - Added connection conn7: url=jdbc:h2:mem:testdb user=SA
DEBUG com.zaxxer.hikari.pool.HikariPool - HikariPool-1 - Added connection conn8: url=jdbc:h2:mem:testdb user=SA
DEBUG com.zaxxer.hikari.pool.HikariPool - HikariPool-1 - Added connection conn9: url=jdbc:h2:mem:testdb user=SA
DEBUG com.zaxxer.hikari.pool.HikariPool - HikariPool-1 - After adding stats (total=10, active=0, idle=10, waiting=0)

5.2 We can use spring.datasource.hikari.* to override the default settings.

application.properties

logging.level.org.springframework=INFO
logging.level.com.mkyong=INFO
logging.level.com.zaxxer=DEBUG
logging.level.root=ERROR

spring.datasource.hikari.connectionTimeout=20000
spring.datasource.hikari.maximumPoolSize=5
spring.datasource.hikari.poolName=HikariPoolZZZ

6. Unit Test

6.1 @DataJpaTest and TestEntityManager to test a Spring data JPA repository.

BookRepositoryTest.java

package com.mkyong;

import org.junit.Test;
import org.junit.runner.RunWith;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.boot.test.autoconfigure.orm.jpa.DataJpaTest;
import org.springframework.boot.test.autoconfigure.orm.jpa.TestEntityManager;
import org.springframework.test.context.junit4.SpringRunner;

import java.util.List;

import static org.assertj.core.api.Assertions.assertThat;
import static org.junit.Assert.assertEquals;

@RunWith(SpringRunner.class)
@DataJpaTest
public class BookRepositoryTest {

    @Autowired
    private TestEntityManager entityManager;

    @Autowired
    private BookRepository repository;

    @Test
    public void testFindByName() {

        entityManager.persist(new Book("C++"));

        List<Book> books = repository.findByName("C++");
        assertEquals(1, books.size());

        assertThat(books).extracting(Book::getName).containsOnly("C++");

    }

}

7. Demo


$ mvn spring-boot:run

INFO  com.mkyong.StartApplication - Started StartApplication in 2.79 seconds (JVM running for 10.883)
INFO  com.mkyong.StartApplication - StartApplication...

findAll()
DEBUG com.zaxxer.hikari.pool.PoolBase - HikariPoolZZZ - Reset (readOnly) on connection conn0: url=jdbc:h2:mem:testdb user=SA
Book{id=1, name='Java'}
Book{id=2, name='Node'}
Book{id=3, name='Python'}

findById(1L)
DEBUG com.zaxxer.hikari.pool.PoolBase - HikariPoolZZZ - Reset (readOnly) on connection conn0: url=jdbc:h2:mem:testdb user=SA
Book{id=1, name='Java'}

findByName('Node')
Book{id=2, name='Node'}

Download Source Code

$ git clone https://github.com/mkyong/spring-boot.git
$ cd spring-data-jpa
$ mvn spring-boot:run

References

About the Author

author image
mkyong
Founder of Mkyong.com, love Java and open source stuff. Follow him on Twitter. If you like my tutorials, consider make a donation to these charities.

Comments

avatar
1 Comment threads
1 Thread replies
1 Followers

Most reacted comment
Hottest comment thread
2 Comment authors
Amlan MohantyAkash Mulik Recent comment authors
newest oldest most voted
Akash Mulik
Guest
Akash Mulik

Please add description for following line:
public interface BookRepository extends CrudRepository {

We have written only one method here. So findAll() and findById() methods are in parent interface??

Amlan Mohanty
Guest
Amlan Mohanty

Yes.. Both the declaration and implementation is there in parent class. That’s the beauty of CrudRepository.
