Spring MVC + Log4j integration example

spring-log4j

In this tutorial, we will show you how to integrate the log4j framework with the Spring MVC web application.

All you need to do is :

  1. Include the log4j.jar as the project dependency.
  2. Create a log4j.properties file and put it into the root of the classpath (for Maven, put it into the resources folder).

Technologies and tools used :

  1. Log4j 1.2.17
  2. Spring 4.0.5.RELEASE
  3. Maven 3
  4. Tomcat 6
  5. Eclipse Kepler 4.3
Note
By default, Spring is using the JCL dependency (commons-logging), and it has a runtime discovery algorithm to find out for other logging frameworks in well known places on the project classpath.

1. Project Directory

Review the final project structure.

spring-mvc-log4j-directory

2. Project Dependencies

Declares the following dependencies :

pom.xml
	<properties>
		<spring.version>4.0.5.RELEASE</spring.version>
		<log4j.version>1.2.17</log4j.version>
		<jstl.version>1.2</jstl.version>
	</properties>

	<dependencies>

		<!-- Spring framework -->
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-core</artifactId>
			<version>${spring.version}</version>
		</dependency>

		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-webmvc</artifactId>
			<version>${spring.version}</version>
		</dependency>

		<!-- Log4j -->
		<dependency>
			<groupId>log4j</groupId>
			<artifactId>log4j</artifactId>
			<version>${log4j.version}</version>
		</dependency>

		<!-- jstl , for JSP, optional -->
		<dependency>
			<groupId>jstl</groupId>
			<artifactId>jstl</artifactId>
			<version>${jstl.version}</version>
		</dependency>

	</dependencies>

3. log4j.properties

Create a log4j properties file, and put it into the resources folder, refer to step #1.

log4j.properties
# Root logger option
log4j.rootLogger=DEBUG, stdout, file

# Redirect log messages to console
log4j.appender.stdout=org.apache.log4j.ConsoleAppender
log4j.appender.stdout.Target=System.out
log4j.appender.stdout.layout=org.apache.log4j.PatternLayout
log4j.appender.stdout.layout.ConversionPattern=%d{yyyy-MM-dd HH:mm:ss} %-5p %c{1}:%L - %m%n

# Redirect log messages to a log file
log4j.appender.file=org.apache.log4j.RollingFileAppender
#outputs to Tomcat home
log4j.appender.file.File=${catalina.home}/logs/myapp.log
log4j.appender.file.MaxFileSize=5MB
log4j.appender.file.MaxBackupIndex=10
log4j.appender.file.layout=org.apache.log4j.PatternLayout
log4j.appender.file.layout.ConversionPattern=%d{yyyy-MM-dd HH:mm:ss} %-5p %c{1}:%L - %m%n

4. Spring MVC Controller + Message Logging

A simple controller to return a welcome page. Furthermore, it shows you how to use log4j to do the message logging.

WelcomeController.java
package com.mkyong.common.controller;

import org.apache.log4j.Logger;
import org.springframework.stereotype.Controller;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RequestMethod;
import org.springframework.web.servlet.ModelAndView;

@Controller
public class WelcomeController {

	private static final Logger logger = Logger.getLogger(WelcomeController.class);

	@RequestMapping(value = "/", method = RequestMethod.GET)
	public ModelAndView getWelcome() {

		//logs debug message
		if(logger.isDebugEnabled()){
			logger.debug("getWelcome is executed!");
		}

		//logs exception
		logger.error("This is Error message", new Exception("Testing"));

		ModelAndView model = new ModelAndView("welcome");
		model.addObject("msg", "Hello Spring MVC + Log4j");
		return model;

	}

}

5. Demo

Run the web application, and access the welcome controller.

5.1 All logging messages will be displayed in the console.

log4j.properties
# Redirect log messages to console
log4j.appender.stdout=org.apache.log4j.ConsoleAppender
log4j.appender.stdout.Target=System.out
log4j.appender.stdout.layout=org.apache.log4j.PatternLayout
log4j.appender.stdout.layout.ConversionPattern=%d{yyyy-MM-dd HH:mm:ss} %-5p %c{1}:%L - %m%n
Eclipse console
Jul 03, 2014 7:19:31 PM org.apache.jk.server.JkMain start
INFO: Jk running ID=0 time=0/11  config=null
Jul 03, 2014 7:19:31 PM org.apache.catalina.startup.Catalina start
INFO: Server startup in 1162 ms
2014-07-03 19:19:43 ERROR WelcomeController:23 - This is Error message
java.lang.Exception: Testing
	at com.mkyong.common.controller.WelcomeController.getWelcome(WelcomeController.java:23)
	at sun.reflect.NativeMethodAccessorImpl.invoke0(Native Method)
	at sun.reflect.NativeMethodAccessorImpl.invoke(Unknown Source)
	at sun.reflect.DelegatingMethodAccessorImpl.invoke(Unknown Source)
	at java.lang.reflect.Method.invoke(Unknown Source)

5.2 Furthermore, a logging file is created in the Tomcat’s logs folder.

log4j.properties
log4j.appender.file=org.apache.log4j.RollingFileAppender
log4j.appender.file.File=${catalina.home}/logs/myapp.log
log4j.appender.file.MaxFileSize=5MB
log4j.appender.file.MaxBackupIndex=10
log4j.appender.file.layout=org.apache.log4j.PatternLayout
log4j.appender.file.layout.ConversionPattern=%d{yyyy-MM-dd HH:mm:ss} %-5p %c{1}:%L - %m%n
D:\apache-tomcat-6.0.37\logs\myapp.log
Jul 03, 2014 7:19:31 PM org.apache.jk.server.JkMain start
INFO: Jk running ID=0 time=0/11  config=null
Jul 03, 2014 7:19:31 PM org.apache.catalina.startup.Catalina start
INFO: Server startup in 1162 ms
2014-07-03 19:19:43 ERROR WelcomeController:23 - This is Error message
java.lang.Exception: Testing
	at com.mkyong.common.controller.WelcomeController.getWelcome(WelcomeController.java:23)
	at sun.reflect.NativeMethodAccessorImpl.invoke0(Native Method)
	at sun.reflect.NativeMethodAccessorImpl.invoke(Unknown Source)
	at sun.reflect.DelegatingMethodAccessorImpl.invoke(Unknown Source)
	at java.lang.reflect.Method.invoke(Unknown Source)
spring-mvc-log4j-file

Download Source Code

Download it – Log4j-SpringMVC-Example.zip (11 KB)

References

  1. Spring Reference – Using log4j
  2. log4j 1.2 official page
  3. log4j hello world example
  4. log4j.properties examples
